harbor 2.9.1 安装
无
2023-11-17 16:45:54
384
0
0
sanger
[TOC] # Harbor 介绍 Harbor 是由 VMware 开源的一款云原生制品仓库，Harbor 的核心功能是存储和管理 Artifact。Harbor 允许用户用命令行工具对容器镜像及其他 Artifact 进行推送和拉取，并提供了图形管理界面帮助用户查看和管理这些 Artifact。在 Harbor 2.0 版本中，除容器镜像外，Harbor 对符合 OCI 规范的 Helm Chart、CNAB、OPA Bundle 等都提供了更多的支持。  如上图所示是 Harbor 2.0 的架构图，从上到下可分为代理层、功能层和数据层。 - 代理层：代理层实质上是一个 Nginx 反向代理，负责接收不同类型的客户端请求，包括浏览器、用户脚本、Docker 等，并根据请求类型和 URI 转发给不同的后端服务进行处理。 - 功能层： - Portal：是一个基于 Argular 的前端应用，提供 Harbor 用户访问的界面。 - Core：是 Harbor 中的核心组件，封装了 Harbor 绝大部分的业务逻辑。 - JobService：异步任务组件，负责 Harbor 中很多比较耗时的功能，比如 Artifact 复制、扫描、垃圾回收等。 - Docker Distribution：Harbor 通过 Distribution 实现 Artifact 的读写和存取等功能。 - RegistryCtl：Docker Distribution 的控制组件。 - 扫描工具Trivy（可选）：镜像的漏洞检测工具。 - Notary（`2.9.1已废弃`）：基于 TUF 提供镜像签名管理的功能。 - ChartMuseum（`2.9.1已废弃`）：提供 API 管理非 OCI 规范的 Helm Chart，随着兼容 OCI 规范的 Helm Chart 在社区上被更广泛地接受，Helm Chart 能以 Artifact 的形式在 Harbor 中存储和管理，不再依赖 ChartMuseum，因此 Harbor 可能会在后续版本中移除对 ChartMuseum 的支持。 - 数据层： - Redis：主要作为缓存服务存储一些生命周期较短的数据，同时对于 JobService 还提供了类似队列的功能。 - PostgreSQL：存储 Harbor 的应用数据，比如项目信息、用户与项目的关系、管理策略、配置信息、Artifact 的元数据等等。 - Artifact 存储：存储 Artifact 本身的内容，也就是每次推送镜像、Helm Chart 或其他 Artifact 时，数据最终存储的地方。默认情况下，Harbor 会把 Artifact 写入本地文件系统中。用户也可以修改配置，将 Artifact 存储在外部存储中，例如亚马逊的对象存储 S3、谷歌云存储 GCS、阿里云的对象存储 OSS 等等。 # 概述 环境：centos 7.x（实际是 Alibaba Cloud Linux (Aliyun Linux) 2.1903 LTS (Hunting Beagle)） 单节点，非集群方式 集群方式需要拆分组件（db、cache和存储），多harbor实例共用这些组件 部署方式：docker compose # 准备 需要先安装docker，新版的docker，yum安装会自动安装docker compose 参考： https://docs.zh3.fun/blog/post/sanger/DockerInstall.sh 在此页面选择最新的offline包，进行下载 https://github.com/goharbor/harbor/releases 下载后解压 ``` wget https://github.com/goharbor/harbor/releases/download/v2.9.1/harbor-offline-installer-v2.9.1.tgz tar xf harbor-offline-installer-v2.9.1.tgz ``` # harbor.yml 配置 ``` #此处要改，用域名或IP都要改 hostname: reg.xxx.com http: port: 80 # 开启https https: port: 443 certificate: /opt/apps/harbor/harbor/certs/tls.pem private_key: /opt/apps/harbor/harbor/certs/tls.key #admin密码，后期可以在UI页面进行修改 harbor_admin_password: Harbor12345 database: password: root123 max_idle_conns: 100 max_open_conns: 900 conn_max_lifetime: 5m conn_max_idle_time: 0 #data_volume 默认是/data，我修改了一下 data_volume: /data/harbor #storage_service 这一段配置是阿里云oss的，默认不配置推送的镜像将存储在本地，需要配置相应的bucket和ram账号及权限 storage_service: ca_bundle: oss: accesskeyid: LTAI5xxxxxxxxxxxxxxzGo6WM accesskeysecret: EVomxxxxxxxxxxxxxxxxxxx5zVs9F region: oss-cn-shenzhen endpoint: xxx-registry.oss-cn-shenzhen-internal.aliyuncs.com bucket: xxx-registry rootdirectory: registry secure: false redirect: disable: false trivy: ignore_unfixed: false skip_update: false offline_scan: false security_check: vuln insecure: false jobservice: max_job_workers: 10 job_loggers: - STD_OUTPUT - FILE logger_sweeper_duration: 1 #days notification: webhook_job_max_retry: 3 webhook_job_http_client_timeout: 3 #seconds log: level: info local: rotate_count: 50 rotate_size: 200M location: /var/log/harbor _version: 2.9.0 proxy: http_proxy: https_proxy: no_proxy: components: - core - jobservice - trivy upload_purging: enabled: true age: 168h interval: 24h dryrun: false cache: enabled: false expire_hours: 24 ``` # 安装 ``` #检查配置文件 ./prepare #安装帮助 ./install.sh -h Note: Please set hostname and other necessary attributes in harbor.yml first. DO NOT use localhost or 127.0.0.1 for hostname, because Harbor needs to be accessed by external clients. Please set --with-trivy if needs enable Trivy in Harbor. Please do NOT set --with-chartmuseum, as chartmusuem has been deprecated and removed. Please do NOT set --with-notary, as notary has been deprecated and removed. #根据提示用 --with-trivy来安装 ./install.sh --with-trivy [Step 0]: checking if docker is installed ... Note: docker version: 24.0.7 [Step 1]: checking docker-compose is installed ... Note: Docker Compose version v2.21.0 [Step 2]: loading Harbor images ... Loaded image: goharbor/harbor-jobservice:v2.9.1 Loaded image: goharbor/harbor-registryctl:v2.9.1 Loaded image: goharbor/harbor-core:v2.9.1 Loaded image: goharbor/harbor-log:v2.9.1 Loaded image: goharbor/harbor-db:v2.9.1 Loaded image: goharbor/harbor-exporter:v2.9.1 Loaded image: goharbor/redis-photon:v2.9.1 Loaded image: goharbor/nginx-photon:v2.9.1 Loaded image: goharbor/registry-photon:v2.9.1 Loaded image: goharbor/trivy-adapter-photon:v2.9.1 Loaded image: goharbor/prepare:v2.9.1 Loaded image: goharbor/harbor-portal:v2.9.1 [Step 3]: preparing environment ... [Step 4]: preparing harbor configs ... prepare base dir is set to /opt/apps/harbor/harbor Clearing the configuration file: /config/log/rsyslog_docker.conf Clearing the configuration file: /config/log/logrotate.conf Clearing the configuration file: /config/portal/nginx.conf Generated configuration file: /config/portal/nginx.conf Generated configuration file: /config/log/logrotate.conf Generated configuration file: /config/log/rsyslog_docker.conf Generated configuration file: /config/nginx/nginx.conf Generated configuration file: /config/core/env Generated configuration file: /config/core/app.conf Generated configuration file: /config/registry/config.yml Generated configuration file: /config/registryctl/env Generated configuration file: /config/registryctl/config.yml Generated configuration file: /config/db/env Generated configuration file: /config/jobservice/env Generated configuration file: /config/jobservice/config.yml Generated and saved secret to file: /data/secret/keys/secretkey Successfully called func: create_root_cert Generated configuration file: /config/trivy-adapter/env Generated configuration file: /compose_location/docker-compose.yml Clean up the input dir Note: stopping existing Harbor instance ... [Step 5]: starting Harbor ... [+] Running 11/11 ✔ Network harbor_harbor Created ✔ Container harbor-log Started ✔ Container harbor-db Started ✔ Container harbor-portal Started ✔ Container redis Started ✔ Container registryctl Started ✔ Container registry Started ✔ Container trivy-adapter Started ✔ Container harbor-core Started ✔ Container nginx Started ✔ Container harbor-jobservice Started ✔ ----Harbor has been installed and started successfully.---- ``` # 验证 解析域名后，就可以正常访问了  #配置LDAP  # 出现的问题 - Q: 推送一直出现retry，retry次数超过限制后报错 received unexpected HTTP status: 500 Internal Server Error - A: 通过排查harbor日志，观察到是阿里云RAM子账号的权限问题 # 参考： https://xie.infoq.cn/article/c54645b4c5f6857b66beec488 https://www.gbase8.cn/10741 https://blog.csdn.net/qq_35036073/article/details/110132910 [Trivy + Harbor实现镜像漏洞的简单、高效扫描](https://blog.51cto.com/lidabai/5846822)
